Reinforced Frames

Reinforced support frames for vehicle-duty grating areas, engineered with the grating, restraints and anchors from project load and support data.

Add to a System Quote See Specifications

Material & finish optionsCarbon steel / SS400 — HDGStainless steel — 304 / 316LOther materials on request

Reinforced industrial steel frame — Representative product geometry. Material, finish, dimensions and performance are confirmed against the project specification.

Configured for industrial projects

Built around your operating conditions.

Reinforced support frames for vehicle-duty grating areas, engineered with the grating, restraints and anchors from project load and support data.

Dimensions, material and finish confirmed against drawings
Engineering support for spans, loads, installation and standards
Coordinated supply with frames, fixings and edge protection

Send requirements for a quote

What we supply

Channel steel frames — [120×55, [140×60, [160×65, [180×70, [200×75 mm. S355JR / ASTM A572 Gr.50
Cross-bracing and vertical stiffeners are positioned at calculated bearing and load-transfer points
Single- or built-up frame construction is selected from the complete assembly calculation and fabrication drawing
EN 124 class numbers are test-load classifications, not axle-tonnage ratings; use them only where the standard applies to the complete verified assembly
Hot-dip galvanized to ASTM A123 / EN ISO 1461. Minimum 100 µm zinc coating for outdoor and industrial
Anchor bolt slots or pre-drilled holes. M20–M36 high-strength bolts, ISO 898-1 Grade 10.9
Frame dimensions, bolt patterns, level-adjustment shims and weld details confirmed per your drawing
